Dynamic Wireless Power Transfer
Dynamic Wireless Power Transfer (DWPT) enables power delivery to moving vehicles or devices, eliminating the need for charging stops.
Integrating our ground assemblies into roads, walls or factory floors enables continuous charging for electric vehicles, drones, robots, Automated Guided Vehicles (AGV), and Automated Mobile Robots (AMR).
DWPT allows smaller batteries, enhances efficiency, and contributes to sustainable, green energy solutions for transportation and smart production.
What We Offer
Feature 1
Design, modelling and simulation of WPT systems
Feature 2
Planning of turn-key WPT solutions
Feature 3
Production and sales of WPT devices
Feature 4
Additional WPT hard- and software modules
Feature 5
WPT systems installation and commissioning
Feature 6
Consulting in the field of WPT technology
Amplink offers cutting-edge Dynamic Wireless Power Transfer solutions. Our technology enables mobile production equipment to charge while in motion, ensuring uninterrupted operations without the need for stops or downtime.
The simple integration methods of our charging pads on top of factory floors, warehouses, or logistics centers enable 24/7 operation of e.g. AGV and AMR, significantly improving efficiency and productivity. No more manual charging, battery swaps, or complex charging stations – our DWPT system delivers continuous power.
DWPT4x3.3 - Product Key Data
Input
DC 650 V, 16 A, max. 11 kW
Output
DC 24…60 V, max. 3.3 kW @ 93%
Direction
Bidirectional energy transfer
Distance
10…40 mm (nominal air gap)
Setup
Modular, up to 4 coils per primary electronics
Charging
On-the-fly adaptable charging profile
Dynamic
Turn-On time < 1 ms, enables transfer during fast movement
Height
6 mm ultra-flat primary coil design
Cabeling
Primary coil cable adaptable in length
Product Features
Flat coil design
Secondary side position detection
High transfer efficiency
Stationary and dynamic power transfer
Interoperable over multiple power classes
Modular components
The AMPLINK 4x3.3 kW prototype system combines dynamic charging with a modular and ultra-flat design. It can transfer a continuous power of 3.3 kW per charging pad. The energy efficiency remains exceptionally high at 93%.
Prototype
Our prototype system can supply multiple battery-free Automated Guided Vehicles in continuous 24/7 operation.
In the video, Amplink demonstrates an Automated Guided Vehicle powered by our Dynamic Wireless Power Transfer system, utilizing six coils for seamless, continuous charging along its designated path.
On the screen, the six coils are shown as blue dots, illustrating how each one activates as the vehicle moves across them.
The screen also displays the vehicle’s DC-link capacitor voltage. As the vehicle moves, the steady increase in voltage demonstrates the effective dynamic energy transfer from the coils to the Automated Guided Vehicle.
The video uses time-lapse to compress the footage, speeding up the vehicle’s operation over a longer period, while an old clock on the screen shows the real-time duration of the experiment.
Details
300 to 3300 W
Variable Transfer Power
> 93 %
Efficiency
24 V to 48 V
Voltage Range
1 to ∞
